Building responsive web layouts using React and styled-components instead of relying on frameworks like Bootstrap. This tutorial demonstrates creating a simple grid view which allows us to split a website into columns.

How Responsive Grid Views Work

Basic Concept

Responsive grids typically contain twelve columns totaling 100% width. Individual columns can merge to create wider sections. The mechanism involves div elements with equal widths that float left to appear in rows.

.column {
  width: 8.33%;
  float: left;
}

Flexbox offers a modern alternative to float: left, though older browser compatibility may be a consideration.

Column Spanning

Rather than using a single column class, individual classes represent each possible span:

[class*="col-"] {
  float: left;
}


.col-1 {
  width: 8.33%;
}


.col-3 {
  width: 25%;
}

Mobile-First Approach with Media Queries

Columns default to 100% width on small screens, then use media queries to adjust for larger viewports:

[class*="col-"] {
  width: 100%;
}


@media only screen and (min-width: 768px) {
  .col-1 {
    width: 8.33%;
  }
  .col-3 {
    width: 25%;
  }
}

Implementation with styled-components

The implementation includes a Row component (to clear floats) and a Column component with default float: left and 100% width.

The Column component accepts a span prop representing the number of columns to span. When set, it calculates the desired width percentage.

Advanced Grid: Multiple Breakpoints

The enhanced version supports different column spans across breakpoints:

• xs: up to 768px
• sm: up to 992px
• md: up to 1200px
• lg: 1200px and larger

Rather than calculating widths, the component generates complete width declarations. If a breakpoint lacks a column span, the next smaller breakpoint's width applies; otherwise, it defaults to 100%.

Conclusion

This demonstrates creating a responsive grid with styled-components with basic functionality. Extensions could include margins, padding, and borders. The approach leverages native CSS media queries rather than JavaScript-based responsive libraries.

For a more advanced alternative, check out grid-styled.
